TECHNICAL SPECIFICATIONS: PC228-LTE
General Information
- POTS Replacement Box
- Dimensions: 230 W x 143 H x 68 D
- Case: Metal
- WAN Ports: 2
- WAN (PoE): 12V / 24V / 48V
- WiFi: Yes
- WAN over WiFi: Yes
- LAN Ports: 2
- FXS Ports: 8
- Power Input: 24V DC
- Battery Input: USB Type C (PD)
Capabilities
- Voice (VoIP): Yes
- Alarm (VoIP): Yes
- Alarm XMTR: Yes
- Elevator: Yes
- FAX (T.38): Yes
- FAX XMTR (Store & Forward): Yes
- Modem (MoIP): Yes
Accessories
- Power Supply: 24V (3 meter)
- 2 Cellular Antennas
- 2 WiFi Antennas
- Mounting Screws: Yes
LTE & Connectivity
- LTE Module: Telit
- LTE Radio Category: Cat 4
- TAA Compliant: Yes
- SIM: 2 (Physical) & 1 (eSIM)
Features
- Dry Contact Interface
- Reset Button
- LED Indicator Lights
- On/Off Button
- LCD Display
- LCD On/Off Button
Battery Specifications
- Battery Type: Li-Ion
- Battery Specs: 8 Cells – 40Ah
- Standby Time: 24+ Hours
- Replaceable Internal Battery
Regulatory and Compliance
- Permitted under NFPA 72 (National Fire Protection Association)
- HIPAA Compliant
- PCI Compliant
- FCC Compliant
- UL Listed
- Managed Facilities Voice Network (MFVN)
- Approved for Fire/Life Safety applications, including elevators and alarm systems
- Tested and extensively accepted by leading fire and burglar panel manufacturers
- Verizon, AT&T, & T-Mobile Certified
